Create or Update Collection

The Create or Update Collection component is a powerful tool in the Retrieval Augmented Generation(RAG) category. It manages a Vector Database collection by allowing you to create a new collection or update an existing one. Specify a database provider, collection name, and partition details while configuring embeddings and document structures. The component supports adding, updating, or deleting documents based on defined conditions, ensuring efficient storage and retrieval of vector-based data.

Overview

The Create or Update Collection component creates or updates Vector Database collections. The component manages the storage infrastructure required for semantic search and vector-based retrieval in GenAI applications.

This component serves as the final step in RAG pipeline preparation, taking chunked text data and converting it into a searchable vector database collection with embeddings.

How to use:

Important

You must use a mandatory custom function which transforms chunk arrays into collection data format. Place the Call Custom Function component immediately after the Chunk Text and before Create or Update Collection.

The custom function should implement following logic:

• Access session data using session = message.request.session and pipeline_id = message.get_arg('pipeline_id').

• For multiple documents (loop scenario): Get current document URL using loop_item = session.get_session_data(pipeline_id, 'loop_item') and extract document name using document_name = os.path.basename(loop_item).

• For single document: Get document name from input parameter using request_inputs = message.request.httpRequest.get("inputs", {}) and document_name = request_inputs.get("input_var_name", "default_value").

• Retrieve processed chunks using chunks = session.get_session_data(pipeline_id, 'doc_chunks').

• Error handling: Raise ValueError if chunks is None or empty. Initialize empty results list.

• Process each chunk in iteration: Generate unique UUID using random_id = str(uuid.uuid4()), create structured entry as chunk_entry = {"id": random_id, "document_name": document_name, "text": chunk}, append to results list.

• Return complete results array. This transformation ensures each chunk becomes a properly structured database record with unique identification, source document tracking, and embeddable text content.

COLLECTION DATA SOURCE: The collection_data input must always use session source pointing to the output variable from the prerequisite custom function (typically mapped as session path like "transformed_chunks" or "collection_ready_data").

Key Terms

When to Use

You can use the Create or Update Collection component when:

• Setting up a new RAG system that requires vector storage.

• You need to store and retrieve data using semantic similarity rather than exact matching.

• To update existing vector collections with new documents or schema changes.

• Building GenAI applications that need to reference external knowledge.

• Implementing semantic search functionality in your Pipeline Builder flow.

Component Configuration

Required Inputs

Optional Inputs

How It Works

1. The component first checks if the specified collection exists in the vector database.

2. If the collection does not exist, it creates a new collection based on the provided schema.

3. If the collection already exists, it validates that the incoming data matches the existing schema.

4. For document updates, the component processes the documents:

   • The specified embed column content is sent to the embedding provider to generate vector embeddings.

   • These embeddings, along with the original document data, are stored in the vector database.

5. If documents are specified for deletion, they are removed from the collection.

6. The component returns a response indicating the success or failure of the operation, including details about any documents that were added, updated, or deleted.

Typical RAG Pipeline Patterns

• Single Document Flow: Download From S3 → Extract Text → Chunk Text → Call Custom Function (transformation) → Create or Update Collection.

• Multiple Documents Flow: Loop → Download From S3 → Extract Text → Chunk Text → Call Custom Function (transformation) → Create or Update Collection(of all chunks of that doc). The component automatically handles collection creation for new collections or updates existing collections with additional data.

• Custom Schema Adaptation: When users specify custom field requirements, modify the document_schema, document_column_names, id_column_name, and embed_column_name inputs accordingly, but maintain the same transformation logic pattern in the prerequisite custom function. The component integrates with Milvus vector database for persistent storage and SentenceTransformer for embedding generation, creating a searchable knowledge base infrastructure ready for RAG query operations.

Example Use Case: Multilingual Knowledge Base

Let's say you're building a multilingual knowledge base for your application documentation:

Scenario

You need to create a vector database collection that stores documentation in multiple languages and allows users to search for relevant information regardless of language.

Configuration

• VectorDB Provider: Milvus - default

• Collection ID: multilingual_docs

• Embeddings Provider: SentenceTransformer_all-MiniLM-L6-v2_384

• ID Column Name: ID

• Embed Column Name: Description

• Document Column Names: ["id", "name", "description", "definition", "language"]

• Document Schema: A JSON object defining the schema with fields for id, name, description, definition, and language

• Filter By Column Names: ["language", "name"]

• Collection Data: An array of documentation entries in various languages

Process

1. The component creates a new vector collection called "multilingual_docs" in Milvus.

2. Each document's description field is converted to vector embeddings using the specified embeddings provider.

3. The documents, along with their embeddings, are stored in the collection.

4. The "language" and "name" fields are set up as filterable fields, allowing users to filter search results by language or document name.

Result

A vector database collection is created that enables semantic search across multilingual documentation. Users can now search for concepts and receive relevant results regardless of the language, and filter results by specific languages if needed.

Best Practices

• Choose the right embed column: Select a column that contains rich, descriptive text that captures the meaning of each document for optimal semantic search performance.

• Design your schema carefully: Plan your document structure with consideration for how you query and filter the data later.

• Use meaningful document IDs: Choose IDs that have semantic meaning when possible to make debugging and data management easier.

• Consider partitioning for large collections: Use partition IDs to organize large datasets, which can improve query performance.

• Include relevant filter columns: Define columns that is commonly used for filtering to optimize search efficiency.

• Batch updates for efficiency: When updating multiple documents, do so in batches rather than individually for better performance.

Troubleshooting

Document Schema Reference

The Document Schema is a critical part of configuring your vector collection. It defines the structure, data types, and properties of the fields in your collection. Here is a detailed explanation of the schema elements:

Schema Structure

Field Definitions

Each field in the schema has the following properties:

Data Types

The vector database supports various data types for fields:

Example Schema

{"auto_id":false,"enable_dynamic_field":true,"fields":[{"field_name":"id","datatype":"DataType.VARCHAR","max_length":100,"is_primary":true,"auto_id":false},{"field_name":"name","datatype":"DataType.VARCHAR","max_length":100},{"field_name":"description","datatype":"DataType.VARCHAR","max_length":2000},{"field_name":"category","datatype":"DataType.VARCHAR","max_length":50},{"field_name":"views","datatype":"DataType.INT64"},{"field_name":"active","datatype":"DataType.BOOL"},{"field_name":"metadata","datatype":"DataType.JSON"}]}

Limitations and Considerations

• Performance with large collections: As your collection grows, search and update operations may become slower. Consider using partitions for better management of large datasets.

• Text length limitations: Be aware of any maximum length constraints for the fields in your schema, especially for text that is embedded.

• Embedding model selection: The choice of embedding model can significantly impact the quality of semantic search results. Consider domain-specific models for specialized content.
