Custom Filters and SQL Expressions for Virtual Fields

Custom GET is used to show preloaded value fetched by the SQL query.

Custom Server-side Scripts for Custom Filters and SQL Expressions

Using the Properties > Custom Server Side Scripts property of an Entity Field, you can specify custom SQL filters and SQL expressions in JSON format.

JSON Structure

Feature

JSON Key

Description

Get Value

get.sql

SQL expression for getting a field's value. Mainly used for Virtual Fields.

Custom Filter

filter.sqlCondition

Custom SQL condition used instead of standard equals/user-defined check.

filter.sqlJoin

SQL join required for the filter.

filter.defaultParams

Default parameters if user input is not present.

Search All

search.sqlCondition

Custom SQL condition for full-text search.

search.sqlJoin

SQL join for full-text search.

search.defaultParams

Default parameters for full-text search.

To Configure Filters or SQL Expressions for a Field

  1. Select the Virtual Field from the list of fields. In the Properties > Custom Server Side Scripts property, enter the JSON. Example below calculates age from a Date of Birth field.

  2. Click Save to save your changes.

Sample Value

{"get":{"sql":" SELECT CONCAT(name, ', ', phone) from Customer c where c.id = e.customerid "},"filter":{"sqlCondition":"(c.name like CONCAT('%', :customerName, '%') OR :customerName = '<NA>')","sqlJoin":" JOIN Customer c on c.id = e.customerid ","defaultParams":{"customerName":"<NA>"}},"search":{"sqlCondition":"(c.name like CONCAT('%', :_searchAll, '%') OR c.address like CONCAT('%', :_searchAll, '%') OR c.phone = :_searchAll)","sqlJoin":" JOIN Customer c on c.id = e.customerid "}}

Examples of SQL Expressions for Virtual Fields

  1. See the Duration field in the XLib.Samples.Todo > Task Entity.

  2. See the Age field in the XLib.Samples.Todo > Employee Entity.

Examples of Custom Filters

See the Assigned To ID field in the XLib.Samples.Todo > Task Entity. (Turn Show Hidden Fields ON)
